Intel is proud to introduce a revolutionary solid-state LiDAR depth technology designed for indoor applications. The first product in the new LiDAR depth family, the Intel RealSense LiDAR Camera L515 is perfect for applications that require depth data at high resolution and high accuracy.
The Intel RealSense LiDAR Camera L515 gives precise volumetric measurements of objects. Use the L515 on a handheld device or as part of an inventory management system for quickly counting objects on a shelf, or track every pallet that leaves your warehouse to make sure it's fully loaded with the right inventory.
Search
Features
Use environment: Indoor Technology: Laser scanning
Ideal range:.25 m to 9 m[1](Range affected by reflectivity)
Depth technology: LiDAR Minimum depth distance(Min-Z) at max resolution: ~25 cm Depth Accuracy:~5 mm to ~14 mm thru 9 m2
Depth Field of View (FOV): 70° × 55° (±3°) Depth output resolution: Up to 1024 × 768 Depth frame rate: 30 fps
RGB frame resolution: 1920 × 1080 RGB frame rate:30 fps RGB sensor technology: Rolling Shutter
RGB sensor FOV (H × V): 70° × 43° (±3°) RGB sensor resolution:2 MP
Form factor: Camera Peripheral Diameter × Height: 61 mm × 26 mm
Connectors: USB‑C* 3.1 Gen 1* Mounting mechanism: – One 1/4‑20 UNC thread mounting point. – Two M3 thread mounting points. – Tripod
